HWACHEON HVT-4550M WITH C-AXIS - USED MACHINE

Updated: May 20

HWACHEON HVT-4550M WITH C-AXIS

USED MACHINE



TABLE DIAMETER: 177.16” RAM DIMENSIONS: 13.77” X 13.77”

MAXIMUM CUTTING DIAMETER: 196.85”

MAXIMUM CUTTING HEIGHT: 98.42”

TABLE SPEEDS, 2-STEP: 1-50 RPM

TABLE WEIGHT CAPACITY: 88,000 LBS X-AXIS TRAVEL: 161.41”

Z-AXIS TRAVEL: 59.05”

W-AXIS TRAVEL: 78.74”

C-AXIS: 0.001 DEG TAPER IN RAM: BT-50 RAPID TRAVERSE, X/Z-AXES: 236.22 IPM RAPID TRAVERSE, W-AXIS: 19.68 IPM CUTTING FEED RATE, X/Z-AXES: 0.039 – 78.74 IPM

CUTTING FEED RATE, C-AXIS: 0 – 180 DEG/MIN

MILLING SPINDLE SPEED: 1500 RPM MILLING SPINDLE MOTOR: 40 HP TABLE MOTOR: 194 HP APPROXIMATE MACHINE FOOTPRINT: 453” X 296”

APPROXIMATE MACHINE HEIGHT: 386”

APPROXIMATE MACHINE WEIGHT: 308,000 LBS


EQUIPPED WITH: SIEMENS 840D CNC CONTROL C-AXIS TABLE MILLING SPINDLE ATC: 12 EA (MILLING: 6EA, CUTTING: 6EA)

177.16" 4-JAW FACE PLATE TYPE CHUCK
